Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation
  • Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation
  • Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation
  • Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation
  • Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation
  • Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation

Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation

Place of Origin China
Brand Name BAOLIDA
Certification ISO9001:2008
Model Number BAOLIDA-LIGHT DEP GREENHOUSE
Product Details
Features:
Economical Benefits
Product Name:
Herb Greenhouse For Sale
Shading System:
External Shading System
Optional System:
Side Ventilation/LED Grow Light/Cooling System
Covering:
Black And White Film
Length:
30-45ft
Span Width:
6-10m
Height:
Customized
Material:
Hot Dip Galvanized Steel
Application:
Plants Cultivation
Load Parameter:
15KG/m²
Highlight:

Single Span Tunnel auto light dep greenhouse

,

auto light dep greenhouse blackout

,

Single Span Tunnel greenhouse blackout

Payment & Shipping Terms
Minimum Order Quantity
500 Square meters
Price
6-15 USD
Packaging Details
Wooden Case Packing
Delivery Time
15 work days
Payment Terms
L/C, D/A, D/P, T/T
Supply Ability
500000 square meters per month
Product Description

Agricultural Single Span Tunnel Blackout Greenhouse Light Deprivation Automatic With Lught



Product Advantages


BAOLIDA Blackout Herb Greenhouse:



1. Low cost: The interior of the greenhouse is covered with transparent film, and the exterior is covered with black and white film. The cost is low and the practicability is strong, which is used for growing herb mushroom and other plants.





2.100% shading: the outer black and white film can achieve 100% shading effect. The light inside the greenhouse can be adjusted by rolling up or down the outer film.





3. Strength factory: Our factory has been specialized in manufacturing greenhouse for 15 years, exporting to North America, Europe, and other countries.



Blackout System


Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation 1

This greenhouse is covered with double layer plastic, the black-white film outside, and transparent PE film inside.

The electric film rolling system can automatically roll up and down the film, and adjust the brightness in the greenhouse.



Product Parameter




Name Specification Remarks
Length 105ft, 120ft, 131ft, 144ft All greenhouse structures and control systems can be customized according to your requirements.
Width 30ft, 35ft, 40ft, 42ft, 45ft
Wind Load ≤0.45KN/m²
Snow Load ≤0.25KN/m²
Load Parameter 15KG/m²
Control System Automatic Control System for Light Deprivation;
Cooling Fan&Pad. Top Ventilation;
Temperature/Humidity/Light Control System;
220v, 230v, 380v, ph1, ph3, 50Hz, 60Hz Available.
Optional System Side/Top Ventilation;
Lighting System;Cooling/Heating/Dehumidifier System;Drip/Micro Irrigation System;
Ebb&Flow Hydroponic Rolling Bench.





Product Details


Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation 2

1.Galvanized Steel Pipes

This blackout greenhouse uses high-quality hot-dip galvanized steel structure, Zinc-coating 275 g/m2, service life over 20 years. All steel materials are field-assembled, no secondary processing required.The galvanized connectors and fasteners are not rusted for 20 years.



2.PE Film

We usually use 150 micron plstic PE film to cover. Depending on the specific type of plastic film used, it can provide excellent light transmission, allowing for optimal plant growth and productivity. High-quality greenhouse plastic film is resistant to tears, punctures, and degradation from sunlight, making it a durable option for greenhouse coverings.



3. Black and White Film

The greenhouse is covered with a black and white film with a thickness of 0.13mm, and the shading effect is 100%. Compared with other materials, black and white film has low cost, but good economic effect, which can meet the temperature and shading effect required by the growth process of vegetable.



4. Side Ventilation

This greenhouse is covered with plastic film and two ventilation systems on both sides with insect nets. The manual film roller can control the upper and lower film coiling, realize ventilation and adjust the temperature in the greenhouse, which can provide  a suitable growing environmentfor crops, such as mushrooms, and medical plants.



5.Top Ventilation Roller

The top is equipped with 220V, 100W electric film roller, which can roll up or put down the black and white film on the surface to achieve the shading effect of the greenhouse.(The side roller also can be electric).



Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation 3

Optional System


LED Grow Light

Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation 4

Baolida light bulbs are all Samsung brand quality light bulbs, the use effect is good. The brightness can be adjusted by one key to meet the lighting conditions of vegetable growth in different periods. LED grow lights are highly energy efficient, using up to 50% less energy than traditional lighting sources. This can result in significant cost savings on electricity bills over time. At the same time, we have different kinds of growth lights to meet your different needs.

Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation 5



Negative pressure fan
Negative pressure fans create negative pressure inside the greenhouse, which draws in fresh air through openings such as vents or louvers. This helps to circulate air and maintain optimal temperature and humidity levels for plant growth.Greenhouse equipped with 220V,50 HZ fan, the wind capacity can be 48800 m²/h.

Wet curtain ( Cooling Pad)
Wet curtains work by absorbing water and allowing it to evaporate, which cools the surrounding air as it passes through the pads. This helps to maintain a more consistent temperature and humidity level inside the greenhouse. Component: Inside pipe, Water pump 380V/220V,three phase/double phase/single phase, 3kw 50HZ.


Greenhouse Project


Single Span Tunnel Auto Light Dep Greenhouse Blackout For Plants Cultivation 6

Greenhouse materials and ancillary equipment can be customized to provide a complete set of greenhouse programs! Please contact us for details!
