Blackout Greenhouse Single Span Auto Small Gutter Backyard Light Dep Greenhouse
Single-Span Greenhouses Plastic Film Small Gutter Connected Light Deprivation Blackout Greenhouse
Product Advantages
- Low cost: Features transparent interior film and black/white exterior film for cost-effective plant cultivation of herbs, mushrooms, and other plants.
- 100% shading: Outer black/white film provides complete light control through adjustable rolling mechanism.
- Strength factory: 15 years of greenhouse manufacturing expertise with global exports to North America and Europe.
Blackout System
This greenhouse features double-layer plastic covering with black-white exterior film and transparent PE interior film. The electric film rolling system automatically adjusts light levels for optimal plant growth.
Light Deprivation Greenhouse - Control Light, Boost Growth!
Key Features:
- Precision Light Control: Complete darkness for optimal flowering cycles
- High Durability: Weather-resistant, corrosion-proof materials
- Energy Efficiency: Advanced insulation reduces operating costs
- Customizable Design: Adaptable for various crops including, flowers, and vegetables
- Easy Automation: Compatible with advanced control systems for light, ventilation, and irrigation
Maximize Yields with Minimal Effort! Ideal for both commercial operations and personal growing with precision agriculture solutions.
Product Parameters
| Name |
Specification |
Remarks |
| Length |
105ft, 120ft, 131ft, 144ft |
All greenhouse structures and control systems can be customized according to your requirements. |
| Width |
30ft, 35ft, 40ft, 42ft, 45ft |
| Wind Load |
≤0.45KN/m² |
| Snow Load |
≤0.25KN/m² |
| Load Parameter |
15KG/m² |
| Control System |
Automatic Control System for Light Deprivation; Cooling Fan&Pad; Top Ventilation; Temperature/Humidity/Light Control System; 220v, 230v, 380v, ph1, ph3, 50Hz, 60Hz Available |
| Optional System |
Side/Top Ventilation; Lighting System; Cooling/Heating/Dehumidifier System; Drip/Micro Irrigation System; Ebb&Flow Hydroponic Rolling Bench |
Product Details
1. Galvanized Steel Pipes
High quality hot-dip galvanized steel structure with 275 g/m² zinc coating for 20+ year service life. All materials are field-assembled with rust-proof connectors and fasteners.
2. PE Film
| Mechanical behavior |
Details |
Test method |
| Tensile strength at break (PMa) |
Longitudinal: 33 Transverse: 35 |
ASTM D882 |
| Elongation at break% |
Longitudinal: 600 Transverse: 650 |
ASTM D882 |
| Tearing strength (Gf/Micr) |
15 |
ASTM D1922 |
| Impact strength (g) |
1000 |
ASTM D1709 |
| Optical performance |
Total light transmittance: ≥91%
Refraction light: ≤20% |
Internal standard |
3. Black and White Film
Thickness: 0.13 mm
Shading rate: 100% shading
Tensile Strength: 35MPa (Vertical and horizontal)
Elongation at break: 800%/1000% (V/H)
Right angle tear strength: 100kN/m/110kN/m (V/H)
Applications: Herb/Mushroom/Animal husbandry
Warranty: 5 years
4. Side Ventilation
Features plastic film covering with dual ventilation systems and insect nets. Manual film rollers control ventilation and temperature for optimal growing conditions for herbs, mushrooms, and medical plants.
5. Top Ventilation Roller
Equipped with 220V, 100W electric film roller for adjusting black/white film position to control shading (side rollers can also be electric).
Optional Systems
LED Grow Light
Passive heat sinking with no fans or noise. Waterproof design with Samsung LM301H LED chips. Foldable with adjustable angles and 0-10V dimmer capability.
Cooling System: Exhaust Fan
Frame size: 1380*1380*400 mm
Voltage: 220V,50 HZ 1.1 kw (three phase/double phase/single phase)
Fan parameters:
- Wind capacity: 48800 m²/h
- Blade size: 710 mm
- Blade speed: 440 r/min
- Motor speed: 1250 r/min
- Air quantity: 760 m³/min
- Noise: ＜65 dB
Cooling System: Cooling Pad
Size: 1.5m*3m
Water system: φ50PVC inlet, φ110 outlet
Pump: 220v*1.5-5 KW independent control
Parameters:
- Component: Inside pipe, Water pump
- Power: 380V/220V, 3kw 50HZ
- Dimensions: 1500mm(H)*3000mm(W)*100mm(T)
- Aluminum frame
- Corrugation angles: 45° (α and β)
Indoor Circulating Fan
Frame size: 480*480*260 mm
Total pressure: 60 pa
Wind capacity: 5500 m³/h
Effective distance: 16-21 m
Output Power: 120 W
Voltage: 220V,50 HZ 1.2kw (three phase/double phase/single phase)
